PROPERTY

VALUE

TEST METHOD

Corrosion of Steel

Pass

C1617

Non-combustibility

Complies

CAN/ULC-S114

Smoulder Resistance Corrosion

Average Mass Loss ≤ 2%, Individual Mass Loss ≤ 3%

CAN/ULC-S129

Surface Burning Characteristics

Flame Spread 0; Smoke Developed 0

CAN/ULC-S102

Fungi Resistance

Pass

ASTM C1338

THERMAL

RESISTANCE

APPLICATION

THICKNESS

WIDTH

LENGTH

COVERAGE/

BAG

RSI

R

SQ. M.

SQ. FT.

2.1

12

Wood Frame

89 mm (3.5")

279 mm (11")

1219 mm (48")

13.65

146.7

381 mm (15")

1194 mm (47")

9.1

97.9

1219 mm (48")

9.29

100

584 mm (23")

1194 mm (47")

13.95

150.1

1219 mm (48")

14.24

153.3

Steel Frame

92 mm (3.625")

406 mm (16")

1219 mm (48")

9.91

106.7

610 mm (24")

1219 mm (48")

14.86

160

2.4

14

Wood Frame

89 mm (3.5")

381 mm (15")

1194 mm (47")

7.28

78.3

584 mm (23")

1194 mm (47")

11.16

120.1

Steel Frame

92 mm (3.625")

413 mm (16.25")

1219 mm (48")

8.05

86.7

3.5

20

Steel Frame

152 mm (6")

406 mm (16")

1219 mm (48")

7.93

85.3

610 mm (24")

1219 mm (48")

11.89

128

3.9

22

Wood Frame

140 mm (5.5")

381 mm (15")

1194 mm (47")

4.55

49

584 mm (23")

1194 mm (47")

6.97

75.1

4.2

24

Wood Frame

140 mm (5.5")

375 mm (14.75")

1194 mm (47")

3.13

33.7

578 mm (22.75")

1194 mm (47")

4.83

52

Steel Frame

152 mm (6")

413 mm (16.25")

1219 mm (48")

3.52

37.9

4.9

28

Unrestricted

Cavity

216 mm (8.5")

381 mm (15")

1219 mm (48")

4.64

50

406 mm (16")

1219 mm (48")

4.95

53.3

610 mm (24")

1219 mm (48")

7.43

80

Cavity

Restricted

178 mm (7")

381 mm (15")

1219 mm (48")

2.79

30

584 mm (23")

1219 mm (48")

4.27

46
